Amplificador Boss Audio Elite de 740W y 5 canales, Clase D
Precio normal
$48499
Total:
Precio unitario
SKU:
BOS/MPD740.5
Precio normal
$48499
Total:
Precio unitario
Descripción
Descripción
Amplificador de 5 canales Clase D Elite de 740 W
Amplificador para auto Boss Audio Systems MPD740.5 Serie Elite de 5 canales Clase D – 740 W de alta potencia, estable en estéreo a 2 ohmios, entradas de bajo nivel, crossover de paso alto/bajo, MOSFET, rango completo, puenteable, conexión a subwoofer para graves.
Características:
- 5/4/3/2 canales
- Rango completo, Clase D
- Fuente de alimentación MOSFET PWM
- Entradas de nivel RCA
- Filtros HP y LP
- Refuerzo de graves (Bass Boost)
- Sensibilidad de entrada
- Puenteable
- Paneles laterales con iluminación LED
- Control remoto de subwoofer
- Clasificación IP66 (a prueba de polvo/resistente a la intemperie)
- Circuitos de protección térmica, contra cortocircuitos y sobrecargas
Specifications
Specifications
Identification
| MPN | MPD740.5 |
|---|---|
| Barcode | 791489133548 |
Dimensions
| Dimensions (H x W x D) | 1.97" x 15.28" x 5.12" (50 x 388 x 130 mm) |
|---|---|
| Weight | - |
Amplifier
| Amplifier Class | Class D |
|---|---|
| Channels | 5 |
Amplifier Power
| Rated Continuous (RMS) Power (Manufacturer Rating @ 4 Ohm) | Main: 60 W x 4/Sub: 160 W x 1 |
|---|---|
| Rated Continuous (RMS) Power (Manufacturer Rating @ 2 Ohm) | Main: 95 W x 4/Sub: 270 W x 1 |
| Rated Continuous (RMS) Power (Manufacturer Rating @ 1 Ohm) | Sub: 400 W x 1 |
Amplifier Processing
| Signal-to-Noise Ratio, referred to highest rated power (A-weighted, 20 Hz-20 kHz noise bandwidth): Analog inputs | - |
|---|---|
| Signal-to-Noise Ratio, referred to 1 W (A-weighted, 20 Hz-20 kHz noise bandwidth): Analog inputs | - |
| Signal-to-Noise Ratio (Manufacturer Rating) | - |
| Damping Factor @ 4 Ω | - |
| Damping Factor @ 2 Ω | - |
| THD+N @ rated power | 0.01% |
| Frequency Response (+0, -1dB) | - |
| Input Voltage Range @ RCA Inputs | - |
| Input Impedance | - |
| Remote Level Control | - |
| Remote Level Modes | - |
| Channel Input Mode Switch | - |
| Pass-through Preamp Output | - |
| Source Channel Selection for PreOuts | - |
Amplifier Filters
| Bass Boost EQ | 0 to +12 dB |
|---|---|
| Output Polarity Switch | - |
| Filter Mode(s): Channels 1 & 2 | High-Pass, Full Range or Low-Pass |
| Filter Slope(s): Channels 1 & 2 | - |
| Filter Frequency Range: Channels 1 & 2 | 50 Hz-250 Hz |
| Filter Mode(s): Channels 3 & 4 | High-Pass, Full Range or Low-Pass |
| Filter Slope(s): Channels 3 & 4 | - |
| Filter Frequency Range: Channels 3 & 4 | 50 Hz-250 Hz |
| Filter Mode(s): Subwoofer Channel | Low-Pass or Full Range |
| Filter Slope(s): Subwoofer Channel | - |
| Filter Frequency Range: Subwoofer Channel | 50 Hz-250 Hz |
| High-Pass/Low-Pass Full Range Filter | - |
| HP Variable Crossover Frequency Range | - |
| LP Variable Crossover Frequency Range | - |
| Infrasonic Filter | - |
| Detented, Calibrated Filter Potentiometers | - |
Electrical
| Operating Voltage | - |
|---|---|
| Current Consumption (idle) | - |
| Current Consumption (standby) | - |
| Fuse Rating | - |
| Recommended Fuse Type(s) | - |
| Minimum Copper Power/Ground Wire Gauge | 4 AWG |
General
| Water/Dust Protection Rating | IP66 |
|---|---|
| Operating Temperature Range | - |
| Protection Circuits | Thermal, overload, speaker short-circuit |
Warranty/Certifications
| Certifications | - |
|---|---|
| Warranty | 2 Years |
