SERIOUS ANGLERS, CRUISERS, SAILORS AND SAIL RACERS DEMAND SERIOUS EQUIPMENT
The easy-to-use, easy-to-install chartplotter/sonar combo delivers MFD performance in a combo-size package.
Get wider viewing angles and superior clarity on the touchscreen with a full HD in-plane switching (IPS) display.
Navigate confidently with built-in Garmin BlueChart G3™.
Easily build your marine system using the best of network connectivity.
See below and around your boat with built-in sonar capabilities (transducers sold separately).
From ANT® technology to Wi-Fi® networking, there are countless ways to connect to your system.
With SmartMode™ station controls, everything is designed to give you quick, one-touch access to the information you need.
Specifications
Specifications
Identification
| MPN | 010-02093-01 |
|---|---|
| Barcode | 753759213534 |
General
| Unit Type | Chartplotter |
|---|---|
| Screen Size | 15.6" |
Display
| Display Type | FHD IPS |
|---|---|
| Resolution | 1920 x 1080 |
| Brightness | - |
| Input | Touchscreen |
Navigation
| GPS / GNSS | - |
|---|---|
| Update Rate | - |
| Preloaded Charts | BlueChart g3 |
| Chart Compatibility | - |
| Card Slots | 2x microSD (32 GB max each) |
| Internal Storage | - |
| Waypoints / Routes / Tracks | 5,000 / 100 / 50 |
Sonar
| Built-In Sonar | No (GCV black box, sold separately) |
|---|---|
| Sonar Power | - |
| CHIRP / Traditional | - |
| Down Imaging | - |
| Side Imaging | - |
| Transducer Port | - |
| Included Transducer | No |
Connectivity
| NMEA 2000 | 1 port |
|---|---|
| NMEA 0183 | 1 in / 1 out |
| J1939 | 1 port |
| Ethernet / Network | 2 Garmin Marine Network ports |
| Wi-Fi | Yes |
| Bluetooth | - |
| Video In / Out | 1 BNC composite in, 1 HDMI in / 1 HDMI out |
Dimensions
| Unit Dimensions (W x H x D) | 15.1" x 10.3" x 3.0" (385 x 263 x 76 mm) |
|---|---|
| Dimensions with Bracket | 16.0" x 11.0" x 4.1" (406 x 279 x 103 mm) |
| Flush Mount Cutout | - |
| Mounting Options | Bail, flat, flush |
| Weight | 9.6 lb (4.4 kg) |
Electrical
| Power Input | 10–32 VDC |
|---|---|
| Power Consumption / Current Draw | 1.3 A typical / 6.0 A max @ 12 VDC |
Additional
| Water Rating | IPX7 |
|---|---|
| Compass-Safe Distance | 41.3" (105 cm) |
| Operating Temperature | 5° to 131° F (-15° to 55° C) |
| Country of Origin | - |
