Dimensions
Dimensions (H x W x D)
2.19" x 16.63" x 8.31" (56 x 422 x 211 mm)
Weight
13.42 lbs (6.09 kg)
Amplifier
Amplifier Class
Class D
Channels
8
Amplifier Power
Rated Continuous (RMS) Power (Manufacturer Rating @ 4 Ohm)
100 W x 8/280 W x 4 (Bridged)
Rated Continuous (RMS) Power (Manufacturer Rating @ 2 Ohm)
140 W x 8
Amplifier Processing
Signal-to-Noise Ratio, referred to highest rated power (A-weighted, 20 Hz-20 kHz noise bandwidth) Analog inputs
-
Signal-to-Noise Ratio, referred to 1 W (A-weighted, 20 Hz-20 kHz noise bandwidth) Analog inputs
-
Signal-to-Noise Ratio (Manufacturer Rating)
85 dB
Damping Factor @ 4 Ω
-
Damping Factor @ 2 Ω
-
THD+N @ rated power
-
Frequency Response (+0, -1dB)
10 Hz-40 kHz
Input Voltage Range @ RCA Inputs
0.3-8 V RMS
Input Impedance
-
Remote Level Control
-
Remote Level Modes
-
Channel Input Mode Switch
-
Pass-through Preamp Output
-
Source Channel Selection for PreOuts
-
Amplifier Filters
Bass Boost EQ
0 to +9 dB
Output Polarity Switch
-
Filter Mode(s) Channels 1 & 2
Low-Pass, High-Pass or Full Range
Filter Slope(s) Channels 1 & 2
-
Filter Frequency Range Channels 1 & 2
32 Hz-320 Hz
Filter Mode(s) Channels 3 & 4
Low-Pass, High-Pass or Full Range
Filter Slope(s) Channels 3 & 4
-
Filter Frequency Range Channels 3 & 4
32 Hz-320 Hz
Filter Mode(s) Channels 5 & 6
Low-Pass, High-Pass or Full Range
Filter Slope(s) Channels 5 & 6
-
Filter Frequency Range Channels 5 & 6
32 Hz-320 Hz
Filter Mode(s) Channels 7 & 8
Low-Pass, High-Pass or Full Range
Filter Slope(s) Channels 7 & 8
-
Filter Frequency Range Channels 7 & 8
32 Hz-320 Hz
High-Pass/Low-Pass Full Range Filter
-
HP Variable Crossover Frequency Range
-
LP Variable Crossover Frequency Range
-
Infrasonic Filter
-
Detented, Calibrated Filter Potentiometers
-
Electrical
Operating Voltage
-
Current Consumption (idle)
-
Current Consumption (standby)
-
Fuse Rating
160 A (4 x 40 A)
Recommended Fuse Type(s)
-
Minimum Copper Power/Ground Wire Gauge
4 AWG
General
Water/Dust Protection Rating
-
Operating Temperature Range
-
Protection Circuits
-
Warranty/Certifications
Certifications
-
Warranty
3 Years
