SERIOUS ANGLERS, CRUISERS, SAILORS AND SAIL RACERS DEMAND SERIOUS EQUIPMENT
ULTRA HIGH-DEFINITION SCANNING SONAR
Get built-in Ultra High-Definition SideVü™ and ClearVü™scanning sonars with vivid, high-contrast color palettes to help distinguish fish from structure. The GPSMAP X3 chartplotter series also supports 1 kW traditional sonar capabilities.
Specifications
Specifications
Identification
| MPN | 010-02367-03 |
|---|---|
| Barcode | 753759250645 |
General
| Unit Type | Chartplotter/Fishfinder Combo |
|---|---|
| Screen Size | 12.1" |
Display
| Display Type | WXGA IPS |
|---|---|
| Resolution | 1280 x 800 |
| Brightness | - |
| Input | Touchscreen |
Navigation
| GPS / GNSS | GPS, GLONASS, Galileo (WAAS) |
|---|---|
| Update Rate | 10 Hz |
| Preloaded Charts | BlueChart g3, LakeVü g3 |
| Chart Compatibility | - |
| Card Slots | 2x microSD (32 GB max each) |
| Internal Storage | - |
| Waypoints / Routes / Tracks | 5,000 / 100 / 50 |
Sonar
| Built-In Sonar | Yes |
|---|---|
| Sonar Power | 1 kW RMS (CHIRP), 500 W RMS (ClearVü/SideVü) |
| CHIRP / Traditional | CHIRP, traditional (50/200, 77/200, 83/200 kHz) |
| Down Imaging | ClearVü (260/455/800 kHz; UHD 800 kHz) |
| Side Imaging | SideVü (UHD 1,200 kHz) |
| Transducer Port | 1x 12-pin |
| Included Transducer | No |
Connectivity
| NMEA 2000 | Compatible |
|---|---|
| NMEA 0183 | 1 in / 1 out |
| J1939 | Compatible |
| Ethernet / Network | 2 Garmin Marine Network ports |
| Wi-Fi | Yes |
| Bluetooth | Yes |
| Video In / Out | 1 BNC composite in |
Dimensions
| Unit Dimensions (W x H x D) | 12.1" x 9.0" x 3.2" (308 x 228 x 82 mm) |
|---|---|
| Dimensions with Bracket | 12.9" x 9.7" x 4.5" (327 x 246 x 114 mm) |
| Flush Mount Cutout | - |
| Mounting Options | Bail or flush |
| Weight | 6.6 lb (3.0 kg) |
Electrical
| Power Input | 10–32 VDC |
|---|---|
| Power Consumption / Current Draw | 1.68 A typical / 3.56 A max @ 12 VDC |
Additional
| Water Rating | IPX7 |
|---|---|
| Compass-Safe Distance | 17.7" (45 cm) |
| Operating Temperature | 5° to 131° F (-15° to 55° C) |
| Country of Origin | - |
