Discontinued

JL Audio | SKU: JLA/98359

JL Audio M Series 800w 8 Channel Amplifier - M800/8

Name: JL Audio M Series 800w 8 Channel Amplifier - M800/8
Brand: JL Audio
SKU: JLA/98359
Price: 1049.99 USD
Availability: OutOfStock

$1,049⁹⁹

Shipping calculated at checkout.

Description

JL Audio's M800/8v2 marine amplifier gives you serious power and incredible versatility. If you're looking for a marine amp with lots of configuration options, this 8-channel powerhouse will give you the flexibility you need to get the sound you want.

The M800/8v2 delivers 75 watts RMS to each of its eight channels, or 100 watts per channel at 2 ohms. JL Audio's NexD™ ultra-high-speed switching design allows for full-bandwidth Class D operation with low distortion and high efficiency. All this performance comes in a low-profile package too, so this amp is great for boats where space is at a premium.

Lots of configuration options
The M800/8v2 includes a frequency filter for each channel bank, which you can configure as a low-pass or high-pass filter. It also features automatic turn-on, along with a dual-range, differential-balanced input section that can handle a wide range of input voltage levels. With the addition of an HD-RLC remote level control (sold separately), you can control the level of two, four, six, or all eight channels from the driver's seat.

Specifications

Identification

MPN	98359

Dimensions

Dimensions (H x W x D)	2.05" x 14.73" x 7.09" (52 x 374 x 180 mm)
Weight	-

Amplifier

Amplifier Class	Class D
Channels	8

Amplifier Power

Rated Continuous (RMS) Power (14.4 V input @ 4 Ohm < 1% THD)	75 W x 8/200 W x 4 (Bridged)
Rated Continuous (RMS) Power (14.4 V input @ 2 Ohm < 1% THD)	100 W x 8
Rated Continuous (RMS) Power (12.5 V input @ 4 Ohm < 1% THD)	60 W x 8/180 W x 4 (Bridged)
Rated Continuous (RMS) Power (12.5 V input @ 2 Ohm < 1% THD)	90 W x 8

Amplifier Processing

Signal-to-Noise Ratio, referred to highest rated power (A-weighted, 20 Hz-20 kHz noise bandwidth): Analog inputs	> 104 dB
Signal-to-Noise Ratio, referred to 1 W (A-weighted, 20 Hz-20 kHz noise bandwidth): Analog inputs	> 84 dB
Signal-to-Noise Ratio (Manufacturer Rating)	-
Damping Factor @ 4 Ω	> 150/50 Hz
Damping Factor @ 2 Ω	> 75/50 Hz
THD+N @ rated power	-
Frequency Response (+0, -1dB)	12 Hz-22 kHz
Input Voltage Range @ RCA Inputs	200 mV - 8 V RMS
Input Impedance	-
Remote Level Control	-
Remote Level Modes	-
Channel Input Mode Switch	-
Pass-through Preamp Output	-
Source Channel Selection for PreOuts	-

Amplifier Filters

Bass Boost EQ	None
Output Polarity Switch	-
Filter Mode(s): Channels 1 & 2	Off, Low-Pass or High-Pass
Filter Slope(s): Channels 1 & 2	12 dB/octave
Filter Frequency Range: Channels 1 & 2	50 Hz-500 Hz
Filter Mode(s): Channels 3 & 4	Off, Low-Pass or High-Pass
Filter Slope(s): Channels 3 & 4	12 dB/octave
Filter Frequency Range: Channels 3 & 4	50 Hz-500 Hz
Filter Mode(s): Channels 5 & 6	Off, Low-Pass or High-Pass
Filter Slope(s): Channels 5 & 6	12 dB/octave
Filter Frequency Range: Channels 5 & 6	50 Hz-500 Hz
Filter Mode(s): Channels 7 & 8	Off, Low-Pass or High-Pass
Filter Slope(s): Channels 7 & 8	12 dB/octave
Filter Frequency Range: Channels 7 & 8	50 Hz-500 Hz
High-Pass/Low-Pass Full Range Filter	-
HP Variable Crossover Frequency Range	-
LP Variable Crossover Frequency Range	-
Infrasonic Filter	-
Detented, Calibrated Filter Potentiometers	-

Electrical

Operating Voltage	12 VDC negative ground (operates down to 10 V)
Current Consumption (idle)	-
Current Consumption (standby)	-
Fuse Rating	80 A
Recommended Fuse Type(s)	MAXI or AGU
Minimum Copper Power/Ground Wire Gauge	4 AWG wire
