KICKER KXMA800.4 4 x 200W 4-Channel Full-Range Class D Amplifier
Description
Description
KXMA800.4 4 x 200W 4-Channel Full-Range Class D Amplifier
The KICKER Real Marine standard means your amplifier is purpose-built for your boat. Every KXMA (and KMA)-Series amp comes complete with an anti-corrosive speaker, power and RCA terminals, stainless-steel screws, conformal-coated circuit boards, and ABYC/NMMA-compliant power connections. KICKER products also undergo rigorous testing to ensure they meet or exceed marine industry standards for UV, humidity, and saltwater exposure. This unparalleled commitment to engineering quality and maritime safety is why our products truly are "Real Marine."
Gain, crossover, and bass-boost controls are protected behind a gasket-sealed panel, as is the control cover hiding the settings, creating a water-resistant barrier to key controls. KickEQ™ delivers as much as a 6dB of extra bump with a simple turn of the knob. A powerful 24dB crossover is also included, letting you quickly tune your system to perfection. A full-range RCA output allows you to easily add another amplifier without running a new signal cable to your KICKER KMC Media Center.
Features:
- Class D Amplifier
- Gain Control With "Gain Match" LED Indicator
- FIT2™ (Fail-safe Integration Technology) Circuitry
- Variable 24dB Crossover
- DSP-Controlled Preamp
- KickEQ™ 6dB Variable Bass Boost
- ABYC/NMMA-Compliant Power Terminals
- Conformal-Coated Circuit Boards
- Easy Access to Settings behind Gasket-Sealed Cover Panel
- Black Anodized Aluminum Chassis
- Top-Mounted, Teal LED Light Pipe
- Stainless-Steel Mounting Hardware Included
Specifications
Specifications
Identification
| MPN | 48KXMA8004 |
|---|---|
| Barcode | 713034020639 |
Dimensions
| Dimensions (H x W x D) | 2.17" x 11.57" x 8.27" (55 x 294 x 210 mm) |
|---|---|
| Weight | - |
Amplifier
| Amplifier Class | Class D |
|---|---|
| Channels | 4 |
Amplifier Power
| Rated Continuous (RMS) Power (14.4 V input @ 4 Ohm < 1% THD) | 100 W x 4/400 W x 2 (Bridged) |
|---|---|
| Rated Continuous (RMS) Power (14.4 V input @ 2 Ohm < 1% THD) | 200 W x 4 |
| Rated Continuous (RMS) Power (12.5 V input @ 4 Ohm < 1% THD) | - |
| Rated Continuous (RMS) Power (12.5 V input @ 2 Ohm < 1% THD) | - |
Amplifier Processing
| Signal-to-Noise Ratio, referred to highest rated power (A-weighted, 20 Hz-20 kHz noise bandwidth): Analog inputs | 95 dB |
|---|---|
| Signal-to-Noise Ratio, referred to 1 W (A-weighted, 20 Hz-20 kHz noise bandwidth): Analog inputs | 75 dB |
| Signal-to-Noise Ratio (Manufacturer Rating) | - |
| Damping Factor @ 4 Ω | - |
| Damping Factor @ 2 Ω | - |
| THD+N @ rated power | - |
| Frequency Response (+0, -1dB) | 10 Hz-20 kHz (+0, -1 dB) |
| Input Voltage Range @ RCA Inputs | 125 mV-5 V (low level); 250 mV-10 V (high level) |
| Input Impedance | - |
| Remote Level Control | - |
| Remote Level Modes | - |
| Channel Input Mode Switch | - |
| Pass-through Preamp Output | - |
| Source Channel Selection for PreOuts | - |
Amplifier Filters
| Bass Boost EQ | 0 to +6 dB @ 40 Hz |
|---|---|
| Output Polarity Switch | - |
| Filter Mode(s): Channels 1 & 2 | Off, High-Pass or Low-Pass |
| Filter Slope(s): Channels 1 & 2 | 24 dB/octave |
| Filter Frequency Range: Channels 1 & 2 | 10 Hz-5 kHz (10X switch) |
| Filter Mode(s): Channels 3 & 4 | Off, High-Pass, Low-Pass or Band-Pass |
| Filter Slope(s): Channels 3 & 4 | 24 dB/octave |
| Filter Frequency Range: Channels 3 & 4 | High-Pass: 10 Hz-500 Hz; Low-Pass: 40 Hz-5 kHz (100 Hz-5 kHz with 10X switch) |
| High-Pass/Low-Pass Full Range Filter | - |
| HP Variable Crossover Frequency Range | - |
| LP Variable Crossover Frequency Range | - |
| Infrasonic Filter | - |
| Detented, Calibrated Filter Potentiometers | - |
Electrical
| Operating Voltage | 10-16 VDC |
|---|---|
| Current Consumption (idle) | - |
| Current Consumption (standby) | - |
| Fuse Rating | 100 A (external, sold separately) |
| Recommended Fuse Type(s) | - |
| Minimum Copper Power/Ground Wire Gauge | 4 AWG |
General
| Water/Dust Protection Rating | - |
|---|---|
| Operating Temperature Range | - |
| Protection Circuits | - |
Warranty/Certifications
| Certifications | - |
|---|---|
| Warranty | - |
